SSZ

Ceramic Angle Valve



   Because of advanced ceramic technology, SSZ has achieved the optimal performance. The sealing surface is easiest to be broken among valve parts. We improve the sealing surface by using ceramics to get a better wear and corrosion resistance.

   The runner of angle valve is simple that is suitable for high viscosity and particulate conditions.



Valve parameters

Size1” – 6”

Temperature range-70°F - 500°F

Pressure levelANSI 150 - 600

Valve body materialsWCB / Other

Sealing surface materialCeramics

Capping formbolt type

Flow characteristicconstant percentage, linear

Leakageless than 0.1% of rated Cv

Adjustable range    501
